DCP007-VIS Process Photometer

High-Precision LED Photometer for In-Line Concentration and Color Measurement.

The Kemtrak DCP007-VIS is a high-performance, fiber optic-coupled photometer designed for real-time, in-line absorbance and color measurements in the visible spectrum. Using a high-intensity LED light source, the system offers drift-free, maintenance-free operation with dual-wavelength functionality to automatically compensate for turbidity and window fouling. The VIS analyzer supports multiple color scales and concentration measurements, ideal for use in chemical, pharmaceutical, food, beverage, pulp & paper, and environmental industries.

Kemtrak DCP007 VIS Photometer

Key Features

LED light source with selectable wavelengths from 350–1050 nm
Dual-wavelength operation for drift-free measurement
Maintenance-free, hygienic measurement cells with sapphire windows
Standard NIST-traceable validation & calibration accessory available
Remote configuration and monitoring via HTML/Java WebUI
Auto zero, auto cleaning, and 16-point linearization capability
Integrated data and event logger with time-stamped ring buffer
Multiple process connection options and rugged construction

Applications

Color scale measurements (Platinum Cobalt, ASTM D-1500, Saybolt, ICUMSA)
Chemical concentration analysis (e.g., ClO2, hypochlorite, metals, aromatics)
Leak, carryover and interface detection
Solvent gradient and polymer reaction monitoring
Inline process control in food, beverage, chemical and water industries

Technical Highlights

Wavelength Range: 350–1050 nm (LED factory installed)
Photometric Range: 0–5 AU @ 500 nm, 10 mm OPL
Accuracy: ±0.001 AU @ 1 AU | Noise: ±0.0001 AU
Linearity: ±0.5% of range
Display: 16×4 alphanumeric LCD with LED indicators
Relay Outputs: 4 x 1 A 240 VAC incl. alarms & cleaning
Analog Output: 1–2 x 0/4–20 mA (galvanically isolated)
PID Control: mA or pulse-width modulated relay output
Remote Access: Ethernet RJ45 (HTML, Java WebUI, MODBUS TCP)
Cleaning Control: Auto/manual trigger, 15 min to 2 month intervals
Housing: Stainless steel (IP65), Flow cell: IP66
Operating Temp: 0–50 °C | Storage: –20 to +70 °C
Power: 100–240 VAC, 50–60 Hz or 22–30 VAC/VDC
Certifications: CE, ISO 9001:2015

Ideal For

Pharmaceutical and biotech industries
Food and beverage production
Chemical and petrochemical processes
Pulp and paper manufacturing
Environmental and water treatment applications
