Portable High-Precision Density Meter

ERADENS X is the world’s smallest and lightest high-precision density meter, designed for accurate and robust density testing both in laboratories and in the field. With its patented vertically aligned x-oscillating metal U-tube, ERADENS X ensures reliable results even under harsh conditions. The device complies fully with ASTM D4052, D5002, and ISO 12185 standards.

Key Features

Xtra Accurate: 5-digit density precision with automatic full-range viscosity correction across 0–100 °C.
Xtra Rugged: No moving parts, housed in corrosion-resistant aluminum. Insensitive to vibrations and shocks.
Xtra Easy: Large touchscreen, intuitive software, and top-side sample introduction. Suitable for right- and left-handed users.
Xtra Compact: The smallest footprint of any high-precision density meter. Lightweight and portable.

Applications

Density measurement of fuels, lubricants, chemicals, beverages, and crude oil
On-site testing in mobile labs, refineries, and terminals
Quality control and R&D in laboratory environments

Technical Highlights

Standards: ASTM D4052, D5002; ISO 12185
Density Range: 0–3 g/cm³
Resolution: 0.00001 g/cm³
Accuracy: 0.00005 g/cm³
Repeatability (SD): 0.000005 g/cm³
Temperature Range: 0–100 °C (accuracy ±0.02 °C)
Sample Volume: 2 mL
Measurement Time: 15 seconds (after temperature equilibration)
Pressure Range: 0–10 bar (absolute)
Bubble Detection: FillingProof™ – automated detection based on density change under pressure
Special Features: Integrated drying pump, Full-range viscosity correction, Built-in ambient pressure sensor
Interfaces: Ethernet, 4× USB, RS232, Wi-Fi (dongle), Direct LIMS connectivity, CSV/PDF export, Optional: keyboard, mouse, barcode reader
Display: 8.4” multilingual color touchscreen
Dimensions: 15.7 × 28.5 × 28.9 cm
Weight: 7 kg
Power Supply: 85–264 V AC or 12 V DC (field use)
Operating Conditions: 5–45 °C, max 90 % RH (non-condensing)

Ideal For

Petroleum Industry: Density and API gravity testing for fuels, crude oils, and lubricants – even in the field.
Chemical & Pharmaceutical Labs: Highly precise density measurements of solvents, reagents, and formulations.
Beverage & Alcohol Industry: Alcohol content determination using programmed conversion tables.
Mobile Testing Units: Rugged construction and compact form make ERADENS X perfect for portable use.
Environmental Monitoring: Accurate testing of waste and process waters under varying conditions.
