Gemini™ Analyzer

Handheld Integrated Raman and FTIR Analyzer for Rapid Chemical Identification

The Thermo Scientific™ Gemini™ analyzer is the first handheld instrument to integrate both Raman and FTIR spectroscopy for rapid, accurate identification of chemicals, explosives, narcotics, and hazardous substances in the field. Built for elite military units, hazmat teams, and first responders, Gemini delivers complementary and confirmatory analysis in a rugged, easy-to-use device. Its intuitive interface, automated scan assist, and mixture analysis capabilities make it an indispensable tool for real-time threat assessment.

Gemini Brochure

Key Features

Dual Technology: Combines Raman and FTIR in a single rugged device
Complementary Analysis: Broader substance ID range with >70% method overlap
Scan Assist: Guides users in selecting the right technology based on sample type
Motorized FTIR Anvil: Enables adjustable pressure and FTIR scan delay for safe analysis
Custom Profiles: Configure scan parameters per user or mission requirements
Durable Design: Drop, shock, vibration, and immersion tested to MIL-STD-810G
User-Friendly: Glove-compatible touchscreen and tactile keypad
Onboard Mixture Analysis: Identifies up to 4 components in a sample
Multilingual Interface: Supports 14 languages for global use
Optional HazMasterG3® Integration: Decision support tool (v1.6+)

Applications

Military EOD and CBRNE response
Hazmat and emergency services
Counter-narcotics and law enforcement
Environmental and industrial monitoring
Border control and customs screening

Technical Highlights

Spectral Range: FTIR: 4,000–650 cm⁻¹ | Raman (785 nm): 250–2,875 cm⁻¹
Spectral Resolution: FTIR: 4 cm⁻¹ | Raman: 7–10.5 cm⁻¹ (FWHM)
Optics: FTIR: Single-bounce ATR diamond | Raman: Fiber optic probe
Display & Interface: Touchscreen + keypad | Scan Delay: Raman and FTIR supported
Battery: Internal Li-polymer + CR123A backup | Power Input: 12V DC, 1.25 A
Data Export Formats: SPC, text, PDF, .rbk (reachback)
Ruggedness: MIL-STD-810G | IP67 sealed
Languages: EN, DE, FR, ES, RU, JP, CN, KR, TR, AR, CZ, PL, PT
Weight: 1.9 kg | Dimensions: 25.6 × 14.6 × 6.1 cm
Operating Conditions: –20 to +50 °C
Add-ons: HazMasterG3 software (optional)

Ideal For

Military and defense chemical reconnaissance
Hazardous material emergency response teams
Police and customs operations
Rapid identification of unknown chemical threats
Field teams requiring dual-method chemical validation
