Viscolite VL7-100B Portable Viscometer Series

Hand-Held Digital Viscometers for Rapid, Reliable On-Site Measurement

The Hydramotion Viscolite VL7-100B series is a range of portable digital viscometers designed for simple, fast, and accurate viscosity measurement in the field or laboratory. Compact and lightweight, the units are fully self-contained and feature an integrated digital display with an internal temperature probe for real-time compensation. With no moving parts and robust stainless steel construction, the Viscolite VL7 is ideal for on-site QA/QC across a wide range of industries.

Key Features

Hand-held design with flexible coil cable and compact digital readout unit
Integrated temperature probe for automatic compensation
Highly polished stainless steel (SS316) sensing surface
Fast 1-second measurement interval
Excellent accuracy and repeatability (±1% / ±0.1 cP)
Wide temperature range (−20 °C to +120 °C)
No moving parts – maintenance free
IP65-rated with durable acetal (Delrin®) enclosure
Battery-powered (4 × AA alkaline cells)

Applications

On-site viscosity testing in QA/QC environments
Industrial, food, cosmetic, pharmaceutical and coating industries
Field service and production line sampling
Lab-scale formulation and analysis

Technical Highlights

**Viscolite VL7-100B-d15**
Viscosity Range: 0 – 5,000 cP
Minimum Sample Volume: 10 ml
Overall Length: 215 mm
Probe Weight: 500 g
Display Unit Weight: 500 g
**Viscolite VL7-100B-d21**
Viscosity Range: 0 – 10,000 cP
Overall Length: 305 mm
Probe Weight: 700 g
Display Unit Weight: 500 g
**Shared Specifications**
Measurement Time: 1 second
Accuracy: ±1% of reading or ±0.1 cP
Repeatability: ±0.5% of reading or ±0.1 cP
Temperature Range: –20 °C to +120 °C
Materials: Wetted Parts – SS316; Enclosure – Acetal (Delrin®)
Ingress Protection: IP65
Power Supply: 4 × AA alkaline batteries

Ideal For

Technicians and field engineers needing portable viscosity checks
Quick spot-checks across diverse sampling points
Environments with limited sample volume (VL7-100B-d15)
Medium-range viscosity testing with robust reach (VL7-100B-d21)
