AMI 310 Multifunction

High-Precision Multifunction Measuring Instrument for Indoor Air Quality and HVAC Applications

The AMI 310 is a versatile and robust multifunction measuring instrument designed for monitoring indoor air quality (IAQ), HVAC systems, and environmental parameters. Built with a modular sensor system, it allows simultaneous measurement of multiple parameters such as CO₂, temperature, humidity, pressure, air velocity, and more. With its ergonomic design, intuitive touchscreen, and wide compatibility with interchangeable probes, the AMI 310 is the ideal portable solution for technicians, engineers, and facility managers.

Sauermann Kimo portable AMI310

Key Features

Multifunctional Measurement: Supports up to 6 interchangeable probes and 6 simultaneous measurements
High Accuracy: Industry-grade sensors ensure precise and reliable readings across all parameters
Customizable Interface: Large color touchscreen with configurable display for real-time data visualization
Modular Sensor Design: Compatible with a wide range of Smart Probes for tailored applications
Data Logging: Internal memory for 1,000 datasets (20,000 points each) plus 4 GB micro-SD card
Wireless Options: Optional Bluetooth or ZigBee module for remote monitoring and data transfer
Rugged Design: Shock-resistant housing with protective rubber grip for field use
Automatic Probe Detection: Plug & Play recognition via mini-DIN connector

Applications

Indoor Air Quality (IAQ) audits and diagnostics
HVAC performance testing and system commissioning
Environmental monitoring in public buildings, clean rooms, and laboratories
Occupational safety and industrial hygiene
Thermal comfort studies and building ventilation assessments

Technical Highlights

Measured Parameters: CO₂, CO, VOC, O₂, temperature, relative humidity, dew point, pressure, air velocity, airflow, tachometry, light
Sensor Inputs: Up to 6 Smart Probes + 2 Pt100 temperature inputs
Display: 4.3″ color LCD (120 × 160 px) with backlight
Memory: 1,000 datasets (20,000 points each) + 4 GB micro-SD card
Interfaces: USB, optional Bluetooth/ZigBee, 2× mini-DIN probe ports
Power Supply: Rechargeable lithium-ion battery; USB charger included
Battery Life: Up to 32 hours (with hygrometry probe)
Operating Conditions: 0 to +50 °C; 0–95% RH (non-condensing); up to 2,000 m altitude
Storage Temperature: –20 to +80 °C
Dimensions & Weight: 215 × 95 × 45 mm | 485 g
Protection Class: IP54 | Housing: ABS/PC and elastomer

Ideal For

HVAC service technicians and installers
Facility and building maintenance teams
Environmental health and safety (EHS) professionals
Laboratories and research institutions
Indoor air quality consultants and auditors
