The Kemtrak UV Spectra is a high performance process analyzer for real time UV absorbance measurement in demanding bioprocess and pharma applications. With user selectable wavelengths from the deep UV up to the visible range, it accurately tracks proteins, peptides, mRNA/DNA and other critical biomolecules directly in the process. The system combines high optical resolution with excellent repeatability, integrated verification and robust digital communication, which makes it ideal for both development and GMP production environments.
Multi wavelength deep UV absorbance from 190 to 440 nm with 1 nm wavelength steps for precise method setup.
High resolution continuous spectrum measurement using a sensitive CMOS linear image sensor.
Zero dead volume hygienic measurement cells with sapphire or fused silica windows, suitable for CIP/SIP and high pressure processes.
Integrated calibration and verification using traceable reference standards and a dedicated verification port between sensor and cell.
Digital connectivity via dual Ethernet interfaces with Modbus TCP, optional Profinet and EtherNet/IP plus flexible analogue and digital I/O modules.
Mercury free UV light source with long service life for stable, environmentally responsible operation.
Protein and API detection with concentration tracking from trace to high levels in downstream processing.
Chromatographic fractionation with precise cut control and interface detection.
Monitoring of filtration, TFF and centrifuge or separator performance in real time.
Leak, carryover and contamination detection in critical bioprocess lines.
Biotech, pharmaceutical and industrial biotech processes that require reliable UV based quality and process control.
Measurement principle: multi wavelength deep UV spectrophotometer with simultaneous sampling of all wavelengths.
Wavelength range: 190 to 440 nm, spectral resolution approx. 5 nm, wavelength reproducibility ±0.5 nm.
Photometric performance: up to 3 AU with a resolution of ±0.005 AU.
Sampling frequency: 10 Hz with measurement updates typically every second.
Process measurement cells: stainless steel or high performance alloys with electropolished hygienic surfaces, sapphire or fused silica windows, surface roughness down to Ra < 0.38 μm.
Operating conditions: process temperatures up to 275 °C and pressures from 10 mbar up to 200 bar, protection up to IP69 depending on cell design.
Analyzer housing: stainless steel enclosure with IP65 protection for indoor or outdoor installation, passive cooling and PoE power supply.
